Application of LED display screen:
LED display, also called led screen, led video wall, led panel ,or led sign, with its unique advantages, has gradually replaced the traditional billboards, light boxes, etc. LED display advertising has become a new force in the media industry.
Traditional advertising can only show pictures, But LED display/led video wall/led screen can perfect combine text, pictures, video, and sound with high resolution, high brightness and full colour! LED display Advertising screen can easily attract the attention of pedestrians, and also are easy to remember, which can generate greater advertising effectiveness.
Led display screen now are widely applied in media advertising, transportation, Security, Real estate and Stage show background.
|
Pixel Pitch
|
2.5 mm
|
|
Module Size
|
320x160mm
|
|
Module resolution
|
128×64 pixel
|
|
Density dot
|
160,000 pixel/sq. m
|
|
Pixel configuration
|
1R1G1B
|
|
The best view distance
|
2.5-30M
|
|
Drive mode
|
1/20 Scan
|
|
Max Power Consumption
|
900W/sq. m
|
|
LED Type
|
SMD1415
|
|
Brightness
|
≥5000nit
|
|
Refresh frequency
|
1920-3840Hz
|
|
View Angle
|
H:110/ V: 90
|
|
Working Environment
|
Temp:-20°C~60°C, Humidity:10%~90%
|
|
Working Voltage
|
AC:100V~120V
AC:220~240V |
|
Lifetime
|
100,000Hours
|
|
IP
|
IP65
|
|
Warranty
|
1-2 years
|
|
Input signal
|
RF,S-VIDEO,RGB,RGBTV,YUT,YC,COMPISITION
|
1. High refresh rate — up to 2000 Hz, ensure to make high definition led video display perfectly.
2. Easy installation and dismantling — quick lock and self-position design, do not need other assistant tools to assemble and disassemble the panels.
3. Transparency —unique design of panel, allow the smoking, lighting, laser and sound effects to pass through the screen to make your stage more amazing.
4. Protection level: IP65 — this led display can prevent dust and rain from entering; can withstand strong winds and extreme weather conditions.
